Northern Design XD-I420 Transducers with 4-20mA Output (24V Loop Powered)
XD Transducer 2
Northern Design XD-I420 Transducers with 4-20mA Output (24V Loop Powered)
£77.00
£92.40 inc. VAT
Product Description
Northern Design's XD-I420 Transducers offer a low-cost, Plate or DIN Rail mounted solution for measuring current and monitoring consumption. The XD-I420-1 model has a current range of 5-30A, XD-I420-2 has a range of 30-100A, and XD-I420-3 has a range of 100-300A. No externals current transformers are required for these readings, making installation simple.
Specification
Input | XD-V5-1 & XD–I420-1: 5, 10, 15, 20, 25 or 30*A XD-V5-2 & XD–I420-2: 15*, 30, 45, 60, 75 or 100A XD-V5-3 & XD–I420-3: 50*, 100, 150, 200, 250 or 300*A *At reduced accuracy |
Frequency Range | 45Hz – 65Hz Standard |
Operating Range | 0 – 120% nominal FS Amp |
Output | 0 – 5V dc max …V |
Response Time | Less than 1 sec |
Accuracy | Better than Class 1 EN 60688 |
Output Burden | 100kΩ min |
Pulse Output | Rating: 50V ac or dc and 100mA max Callibration: 230V at PF=1 1f or 3f, user selectable 100 or 1000 pulses/kWh |
Aux Supply | None |
Max Cable Diameter | XD-1 Models: 10mm XD-0, -2 & -3 Models: 19mm |
Input to Output | 4kV 50Hz 1 sec test |
XD Dimensions | 95 x 52 x 32mm 99mm above & 52mm along rail |
Operating Temp Range | -10ºC to + 65ºC |
Storage Temp Range | -40ºC to + 85ºC |
Humidity | < 95% non-condensing |
Protection Category | IP50 |
Plate | 35 x 38 mm Fixing Centres |
DIN Rail | TS35 DIN Rail (Clips supplied) |
