Hobut Encapsulated Multi-Ratio Split Core Current Transformers (Size 1 & 2 100-1000A)
£66.95
£80.34 inc. VAT
Product Description
Hobut's Encapsulated Multi-Ratio Split Core Current Transformer has four or five built-in current ratios in one product. It is suitable for use up to 1000A using cable primaries. The split-core design allows installation into existing networks without disconnecting cables or busbar circuits.
Product | Class Accuracy | Measuring Range | VA | Dimensions (WxHxD) |
Size 1 | 1 | 100A-200A-300A-400A/5A | 100A 1.5VA, 200A 3VA, 300-400A 5VA | 132 x 113 x 40mm |
| Size 2 | 1 | 200A-400A-600A-800A-1000A/5A | 200A 2.5VA, 400-1000A 5VA | 132 x 125 x 38mm |
Specification
| Frequency Range | 50-60Hz |
|---|---|
| Insulation Level | 3kV for 1 minute |
| Conformity | IEC 185/BS7626 and BSEN 60044-1/IEC 60044-1 |
| Ambient Temperature | -30°C to 80°C |
| Continuous current | 1.2 x rated current |
