Chauvin Arnoux CA8331 Qualistar+ Power Analyser (P01160511)
£1,428.00
£1,713.60 inc. VAT
£2,320.00
£2,784.00 inc. VAT
Designed for inspection and maintenance teams in industrial or administrative buildings, Chauvin Arnoux's CA8336 Qualistar+ Power Analyser can provide a snapshot of the main electrical network quality characteristics. Easy to handle and precise, this instrument also offers a large number of calculated values and several processing functions.
Product includes: 4 mm banana voltage leads, crocodile clips, a set of colour rings for identifying the leads and inputs, a USB cable, a mains power cable, a mains power pack, a safety datasheet, a multi-language operating manual CD and a PC data analysis software disk.
Model: |
CA 8331 |
C.A 8333 |
C.A 8336 |
C.A 8435 |
Number of Channels |
3U/ 4I |
4U/4I |
||
Number of Inputs |
4V/3I |
5V/4I |
||
Voltage (TRMS AC + DC) |
2V to 1000V |
|||
Voltage Ratio |
up to 500kV |
|||
Current (TRMS AC+DC) - Range dependant on clamp used - sold separately: | ||||
MN93 Current Clamp | MN93: 500mA to 200A AC; MN93A: 0.005A AC to 100A AC |
|||
C193 Current Clamp | 1A to 1000A AC |
|||
Mini-AmpFLEX MA193,200mm | 100mA to 10000A AC |
30A to 6500A AC |
||
PAC93 Current Clamp | 1A to 1300A AC/DC |
|||
E3N Current Clamp | 50mA to 100A AC/DC |
|||
Current Ratio |
Up to 60kA |
|||
Frequency |
40Hz to 69Hz |
|||
Power Values |
W, VA, var, VAD, PF, DPF, cos φ, tan φ |
|||
Energy Values |
Wh, varh, VAh, VADh |
|||
Harmonics |
Yes |
|||
THD |
Yes, orders 0 to 50, phase |
|||
Expert Mode |
- |
Yes |
||
Transients |
- |
50 |
210 |
|
Flicker (Pst & Plt) |
Yes |
|||
Inrush Mode |
- |
Yes on 4 periods |
Yes > 10 minutes |
|
Unbalance |
Yes |
|||
Recording MIN/MAX |
Yes |
|||
Recording of a selection of parameters at the max sampling rate | 4 hours to 2 weeks |
Few days to several weeks |
2 weeks to several years |
|
Alarms |
- |
4000 of 10 different types |
10000 of 40 different types |
|
Peak |
Yes |
|||
Vectorial Representation |
Automatic |
|||
Display |
Colour 1/4 VGA TFT screen, 320 x 240, diagonal 148mm |
|||
Capture of Screens and Curves |
12 |
50 |
||
Electrical Safety |
IEC 61010 1000V, CAT III / 600V CAT IV |
|||
Protection |
IP53 / IK08 |
IP67 |
||
Languages |
More than 27 |
|||
Communication Interface |
USB |
|||
Battery Life |
Up to 13 Hours |
|||
Power Supply |
9.6V NiMH rechargeable battery or external mains charger |
|||
Dimensions |
240 x 180 x 55mm |
270 x 250 x 180mm |
||
Weight |
1.9kg |
3.7kg |
