Meanwell HDR-15-24VDC 15.2W
£25.00
£30.00 inc. VAT
Product Description
The HDR-15-24 AC/DC 1-DIN Module wide power supply with 85-264VAC, output 24VDC at 0.63A
Specification
| AC or DC Output Voltage | dc |
| Input Voltage | 120 → 370 V dc, 85 → 264 V ac |
| Output Voltage | 24V dc |
| Output Current | 630mA |
| Power Rating | 15.2W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 90mm |
| Series | HDR |
| Output Voltage Adjustment Range | 21.6 → 29V |
| Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
| Mounting Type | DIN Rail Mount |
| Depth | 54.5mm |
| Width | 17.5mm |
| Maximum Temperature | +70°C |
| Special Features | Small & Compact |
| Load Regulation | ±1% |
| Ripple And Noise | 150mV Pk-Pk |
| Minimum Temperature | -30°C |
| MTBF | 1166kh |
