• External & eSIM options
• eUICC & iUICC capability
• Supports 4G CAT1 bis and 2G
• Smart resilient SIM support
• Remote configuration and status via app or browser
• Low power for critical metering applications
• Elster A1140 and A1120 dedicated meter interface
• Fully powered from meter interface
• FOTA support
• External and internal antenna, auto diversity.

The iCell1140 is designed to fit the standard Elster A1140 meter range, and interfaces with the proprietary interface via an RJ12 connector.

It clips into place conveniently under the A1140 series terminal covers. A suitable antenna can be fitted via the flying lead or mounted remotely via an extension cable if required, to complement the internal antenna. Both internal and external antennas work together to provide signal diversity.

The i-Cell 1140-bis 4G modem supports worldwide 4G Category 1 bis as an always on network, offering improved performance over LTE M1/NB1 (NBloT) communications for many applications, as well as providing legacy 2G quad band support. lt features a maximum downlink and uplink data rate of approx 10Mbps.

This next generation product supports all the new features specified by 3GPP to boost loT applications, such as Power Saving Mode (PSM) and extended Discontinuous Reception (eDRX), which along with proprietary firmware from Wireless lnnovation allows the modem to wake up periodically to deliver data and then go back to sleep, providing ultra low power consumption for long term battery applications.
